PYLON Diamond 28 MKII

Keine weiteren Bilder vorhanden.

>

>

Standlautsprecher

>

PYLON Diamond 28 MKII

PYLON Diamond 28 MKII

Standlautsprecher

€ 1,00 EUR

Abmessungen
Abmess.:
196
cm x
1038
cm x
500
cm
Gewicht
Gewicht:
25
kg

Dieses Produkt mit

anderen vergleichen...

Farben:

Schwarz matt

Weiß matt

Walnuss

PYLON Diamond 28 MKII

Splendid sound and finish - the second biggest representative of the Diamond series combines the sound characteristic of the mighty 30 in a slightly more compact form.

‍

In the 2,5 - way design well known and widely appreciated 19mm Scan Speak textile

dome was used, while the mid’s and the down’s of the band entrusted with a pair of

18cm transducers made by Norwegian Seas. By optimizing the selection of the

tweeters transducers we have obtained sophisticated sustain of high frequencies,

while mid-woofers, with light cellulose membrane allow for a lot of flexibility division

band in the midrange. The whole results in a dynamic, coherent and retail nature of

the presentation that is dierentiating recordings well.

By a slight inclination of the design the desired visual eect was achieved, and it was

combined with the optimization of the dependence phase that occur between the

loudspeakers. In Diamond 28 the crossover is mounted on technique direct mounting,

it uses only polypropylene capacitors. Placement of coils is optimized to minimize

interference.

Loudspeakers enclosures are made of solid MDF, which additionaly were strengthe-

ned with inner rim. To suppress the sound bitumen mats and sheep's wool were

applied. The loudspeaker was set on a pedestal, which in addition to providing

aesthetic impressions, provides an anti-vibration platform for the loudspeaker.

Diamond 28 is the unique combination of natural sounding with the look of the design

‍

‍

Features

Features

Technische Daten

Frequenzgang: 36-20k Hz
Impedanz: 4 Ohm
Wirkungsgrad: 90 dB
Max. Leistung: 250W
Sinusleistung: 120W
Raumgröße: 25-45 m2
Gewicht: 25 kg / Stk.
Abmessungen (B x H x T): 196 x 1038 x 500 mm
